In Bazhou, China, a city steeped in Song Dynasty legacy, nightfall brings more than lanterns. At the Great Song Nightless City cultural tourism project, visitors now encounter a breathtaking fusion of cutting-edge technology and ancient heritage: a massive outdoor holographic screen, measuring 5.6 meters wide and 1.6 meters tall, formed by 256 IPX6 waterproof 80cm holographic fans arranged in a 32×8 grid. This monumental installation does not just display images—it resurrects five legendary historical figures from Bazhou’s past, reenacts epic battles, and immerses tourists in the city’s thousand-year story through stunning, glasses-free 3D visuals that appear to float in the night air.
This case study explores the design, installation, and spectacular results of one of China’s largest outdoor holographic cultural installations, where AIHOLO technology and custom 3D content combine to create an unforgettable night tourism experience.
The Vision: Bringing Bazhou’s Song Dynasty Heritage to Life
Bazhou holds a distinguished place in Chinese history, especially during the Song Dynasty, when it served as a strategic military and cultural hub. The goal for the Great Song Nightless City project was to move beyond static displays and passive storytelling. The curators wanted a dynamic, immersive experience that would:
- Introduce key historical figures associated with Bazhou in a way that felt immediate and alive.
- Depict pivotal war scenes with cinematic scale and emotional impact.
- Engage a modern audience with technology that feels magical yet culturally respectful.
- Withstand outdoor conditions for year-round operation in a public space.
The Solution: A 32×8 Waterproof Holographic Video Wall
The Core Technology – 256 IPX6 80cm Fans
The chosen solution was a massive array of 256 units of our A80 IPX6 waterproof 80cm holographic fans. Each fan is rated IPX6, meaning it is fully protected against powerful water jets, ensuring reliable outdoor operation in rain, humidity, and temperature fluctuations. Arranged in a 32-column by 8-row configuration, the fans form a seamless 5.6m × 1.6m display canvas—perfect for life-size human figures and dynamic panoramic scenes.
H3: Custom 3D Content – Five Historical Figures & War Epics
Content was as critical as hardware. Our in-house creative team worked closely with historians and the project’s cultural consultants to design authentic, visually stunning 3D animations that bring Bazhou’s story to life. The content features:
- Five Legendary Figures: Generals, scholars, and cultural icons from the Song Dynasty, each rendered in exquisite detail, appear in sequence or interact in dramatic scenes.
- Historic War Tableaux: Large-scale battle sequences unfold across the screen, with cavalry charges, siege engines, and swirling banners that seem to burst from the night.
- Cultural Symbolism: Motifs of peonies, calligraphy, and traditional architecture weave through the narratives, grounding the spectacle in authentic heritage.
Each scene was optimized for the unique properties of holographic display—deep black backgrounds, rich contrast, and motion that leverages the fans’ high refresh rate to maintain fluid, realistic action.
Key Features & Benefits of the Installation
All-Weather Reliability
With IPX6 waterproof fans, the installation operates flawlessly through Bazhou’s humid summers, rainy seasons, and even dusty conditions. The robust aluminum alloy construction ensures long-term durability with minimal maintenance.
Life-Size Historical Presence
The 1.6-meter height is perfect for human-scale figures, allowing historical characters to appear as if they are standing before visitors. This scale creates a powerful sense of presence, making the past feel immediate and tangible.
Seamless Splicing for Cinematic Impact
Despite being composed of 256 individual fans, the seamless splicing technology ensures zero visual gaps or shadows. The result is a single, continuous canvas that can display panoramic battle scenes or full-length portraits without interruption.
H3: 2500+ Nits Day & Night Visibility
Even in the ambient light of the night market or early evening, the 2500+ nits brightness ensures content remains vivid and clear. The display transitions gracefully from twilight to full darkness, maintaining its visual impact throughout operational hours.
H3: Smart Cloud Management
All 256 fans are managed via a centralized cloud platform, allowing the operations team to update content, synchronize playback, and monitor system health remotely. New historical vignettes or seasonal content can be deployed instantly without physical intervention.
Technical Specifications of the 32×8 Wall
| Component | Detail |
|---|---|
| Array Size | 32 columns × 8 rows |
| Total Fans | 256 units |
| Fan Model | A80 80cm IPX6 Waterproof Holographic Fan |
| Total Display Area | 5.6 m (W) × 1.6 m (H) |
| Resolution per Fan | 2048×896 pixels |
| Total System Resolution | Approx. 65,536 × 7,168 pixels (aggregate) |
| Brightness | 2100-2500 nits (adjustable) |
| Pixel Pitch | P1.719 mm |
| Waterproof Rating | IPX6 (Powerful water jet protection) |
| Control | Cloud-based central management |
| Content | Custom 3D animations of historical figures & battle scenes |
Main Advantages of the 32×8 Holographic Wall
- Unmatched Scale & Immersion: The 5.6m × 1.6m seamless screen provides a cinematic canvas that envelops visitors in the historical narrative.
- Cultural Authenticity: Custom 3D content created by our team ensures historical accuracy and artistic excellence, deeply resonating with local pride.
- Weatherproof & Durable: IPX6-rated fans are built for continuous outdoor operation, eliminating concerns about rain, dust, or humidity.
- Low Maintenance: The aluminum alloy construction and high-reliability components minimize operational downtime and service requirements.
- Future-Proof Flexibility: Cloud-based content management allows the installation to evolve with new stories, seasonal themes, or special events without hardware changes.
Custom Solution & Support
For this landmark project, AIHOLO provided a comprehensive turnkey solution:
- Hardware Supply & Engineering: 256 IPX6 waterproof fans with custom mounting structures for the outdoor setting.
- Content Creation: Full design and production of historical 3D animations, including character modeling, scene composition, and motion graphics.
- Installation Support: On-site guidance for seamless alignment and synchronization of the 32×8 array.
- Ongoing Technical Support: Remote monitoring and content update assistance via cloud platform.
Products Details
The A80 80cm IPX6 Waterproof Holographic Fan is the building block of this monumental installation. Each fan features:
- IPX6 Waterproof Rating – Direct outdoor use without additional enclosures.
- Ultra-HD Resolution – 2048×896 pixels per fan.
- High Brightness – 2100-2500 nits for day & night visibility.
- Aluminum Alloy Construction – Lightweight, durable, and thermally efficient.
- Cloud-Ready – Seamless synchronization for large-scale arrays.
Frequently Asked Questions (FAQs)
Q1: How does the IPX6 rating ensure reliability in outdoor conditions?
A: IPX6 certification means each fan is protected against powerful water jets from any direction. This makes them ideal for rain, snow, and high-humidity environments without requiring additional protective housings.
Q2: How was the content synchronized across 256 fans?
A: Our cloud-based control system manages all fans as a single canvas. Content is distributed in real-time, with automatic synchronization ensuring perfect alignment across the entire 32×8 array.
Q3: What is the viewing distance for optimal experience?
A: The 5.6m × 1.6m screen is designed for viewing from 3 to 15 meters. The high brightness and wide viewing angle ensure clarity for crowds gathered in the night market area.
Q4: Can the content be updated for different seasons or events?
A: Yes. The cloud platform allows the operations team to update content instantly. New historical vignettes, holiday themes, or special announcements can be deployed without physical access to the fans.
Q5: How does the installation handle power and data for 256 fans?
A: The system is engineered with distributed power and data networking. Each fan connects to a centralized control hub, simplifying cable management and ensuring redundancy for continuous operation.
